Universal Pin Mill

Stainless steel or mild steel construction
Dust collecting device available
No dust flying
Quantity:
Inquire Add to Basket

  • CWU30

  • CHENWEI

  • 10 mm

  • 20-120 mesh

  • Water cooling

  • 10-2000kg

  • SUS304

  • salt,sugar,pepper etc

The pin mill consist of hopper,fixed discs,rotating discs,motor,dust collector  (optional),control box and other related parts.It makes use of the high speed relative  movement of the movable fixed disc and the rotating disc to crush the materials through the comprehensive effect of striking and friction of the fluted disc as well as the mutual striking of the materials. the crushed material can be discharged directly from the grinding chamber of the  machine and the desired granule size can be obtained by installing screens with different apertures. Besides, the whole machine is made of stainless steel.   The inner surface of the enclosure becomes smooth through processing,thus changing the powder residual       phenomenon due  to the coarse inner surface  of the previous models. As a result, the     production of medicine, food and   chemical products can better conform to the national standard and the GMP  requirement.

Techinical Data
Model CWUP20 CWUP30 CWUP40 CWUP60 CWUP80
Capacity(kg/h) 20-150 30-300 40-500 60-600 80-1000
Speed of principle axis (rpm) 4500 3800 3400 2400 2200
Size of input granule (mm) 6 10 12 15 15
Crushing Fineness (mesh) 12-120 12-120 12-120 12-120 12-120
Power (kw) 4 5.5 7.5 22 37
Weight (kg) 280 350 480 650 1050

Our machines have an automatic 12 months guarantee against faulty material and workmanship valid from the date of dispatch in China or date of arrival at foreign border.
If any problem of the machine under instruction within one year,we are responsible for replacement incuding delivery fee and maintenance.
Lifelong service is offered with cost charge after one year.
